Item # 10400
HLCBSC8-07 NATURAL
Quantity Price Break
| UM | Qty | Price |
|---|---|---|
| EA | 1 | $0.46375 |
| EA | 50 | $0.23188 |
| EA | 100 | $0.20611 |
| EA | 200 | $0.18550 |
| EA | 500 | $0.16864 |
| EA | 1,000 | $0.15458 |
| EA | 2,000 | $0.14269 |
| EA | 5,000 | $0.13250 |
| EA | 10,000 | $0.12367 |
| EA | 15,000 | $0.11594 |
Add to Cart to Request Quote for Larger Qtys
Click image to enlarge
Item # 10400
HLCBSC8-07 NATURAL
- UM: EA
- Weight: 0.0008
- Brand: HEYCO PRODUCTS
Specifications
| Description | HLCBSC8-07 |
| Color | Natural |
| Flammability Rating | 94V-2 |
| Maximum Thickness PCB (in) | .062 |
| Maximum Thickness PCB (mm) | 1.6 |
| Maximum Thickness Chassis (in) | .062 |
| Maximum Thickness Chassis (mm) | 1.6 |
| Mounting Hole Diameter PCB (in) | .125 |
| Mounting Hole Diameter PCB (mm) | 3.2 |
| Mounting Hole Diameter Chassis (in) | .187 |
| Mounting Hole Diameter Chassis (mm) | 4.8 |
| A: Spacing (in) | 0.437 |
| A: Spacing (mm) | 11.1 |
