Item # 2017
SB 375-281 BLACK
Quantity Price Break
| UM | Qty | Price |
|---|---|---|
| EA | 1 | $0.19780 |
| EA | 100 | $0.15824 |
| EA | 500 | $0.11303 |
| EA | 1,000 | $0.07912 |
| EA | 2,000 | $0.07193 |
| EA | 5,000 | $0.06593 |
| EA | 7,500 | $0.06086 |
| EA | 15,000 | $0.05651 |
| EA | 30,000 | $0.05275 |
| EA | 60,000 | $0.04945 |
Add to Cart to Request Quote for Larger Qtys
Click image to enlarge
Item # 2017
SB 375-281 BLACK
- UM: EA
- Weight: 0.0009
- Brand: HEYCO PRODUCTS
Specifications
| Description | SB 375-281 |
| Color | Black |
| Panel Thickness Max. (in) | 0.170 |
| Panel Thickness Max. (mm) | 4.3 |
| Mounting Hole Diameter (in) | 0.375 |
| Mounting Hole Diameter (mm) | 9.5 |
| A: Inside Diameter (in) | 0.28 |
| A: Inside Diameter (mm) | 7.1 |
| B: Head Diameter (in) | 0.47 |
| B: Head Diameter (mm) | 11.9 |
| C: Overall Height (in) | 0.41 |
| C: Overall Height (mm) | 10.3 |
Documents
×
