Item # 3447
RLTF 9 GRAYw/3168 NUT
Click image to enlarge
Item # 3447
RLTF 9 GRAYw/3168 NUT
- UM: EA
- Weight: 0.0195
- Brand: HEYCO PRODUCTS
Specifications
| Description | RLTF 9 |
| Color | Gray |
| Cable Diameter Range (in) | .069 - .187 |
| Cable Diameter Range (mm) | 1.8 - 4.7 |
| Thread Size | PG 9 |
| Locknut | Included |
| A: Clearance Hole Diameter (in) | 0.599 |
| A: Clearance Hole Diameter (mm) | 15.2 |
| B: Maximum O.A. Length (in) | 1.30 |
| B: Maximum O.A. Length (mm) | 33.0 |
| C: Thread Length (in) | 0.34 |
| C: Thread Length (mm) | 8.6 |
| D: Wrenching Nut Thickness (in) | 0.20 |
| D: Wrenching Nut Thickness (mm) | 5.1 |
| E: Wrenching Nut Flat Size (in) | 0.75 |
| E: Wrenching Nut Flat Size (mm) | 19.1 |
Documents
Alternate Products
- 4759
- RLTF 9 GRAY-NO NUT
