Item # 4016B
LTB 70-100/PG11 BLACK
Quantity Price Break
| UM | Qty | Price |
|---|---|---|
| EA | 1 | $1.19867 |
| EA | 50 | $1.02743 |
| EA | 100 | $0.79911 |
| EA | 200 | $0.71920 |
| EA | 300 | $0.65382 |
| EA | 600 | $0.59933 |
| EA | 1,800 | $0.51371 |
| EA | 3,000 | $0.47947 |
| EA | 6,000 | $0.44950 |
Add to Cart to Request Quote for Larger Qtys
Click image to enlarge
Item # 4016B
LTB 70-100/PG11 BLACK
- UM: EA
- Weight: 0.0150
- Brand: HEYCO PRODUCTS
Specifications
| Description | LTB 70-100/PG11 |
| Color | Black |
| Panel Thickness (in) | 0.04 - 0.16 |
| Panel Thickness (mm) | 1.0 - 4.0 |
| Mounting Hole Diameter (in) | 0.750 |
| Mounting Hole Diameter (mm) | 19.0 |
| Cable Diameter Range (in) | .28 - .39 |
| Cable Diameter Range (mm) | 7.0 - 10.0 |
| Hole Size | PG11 |
| D: Head Diameter (in) | 0.98 |
| D: Head Diameter (mm) | 25.0 |
| L: Overall Length (in) | 0.83 |
| L: Overall Length (mm) | 21.0 |
| H: Head Thickness (in) | 0.28 |
| H: Head Thickness (mm) | 7.0 |
