Item # 9762
CG 50A-450 (BLUE GLAND)
Quantity Price Break
| UM | Qty | Price |
|---|---|---|
| EA | 1 | $12.20513 |
| EA | 25 | $9.71429 |
| EA | 50 | $7.32308 |
| EA | 100 | $6.80000 |
| EA | 200 | $6.52055 |
| EA | 500 | $6.34667 |
| EA | 1,000 | $5.95000 |
Add to Cart to Request Quote for Larger Qtys
Click image to enlarge
Item # 9762
CG 50A-450 (BLUE GLAND)
- UM: EA
- Weight: 0.1100
- Brand: HEYCO PRODUCTS
Specifications
| Description | CG 50A-450 |
| Cable Diameter Range (in) | .350 - .450 |
| Cable Diameter Range (mm) | 8.9 - 11.4 |
| Thread Size | 1/2 |
| Gland Color | Blue |
| A: Clearance Hole Diameter (in) | 0.875 |
| A: Clearance Hole Diameter (mm) | 22.2 |
| B: Sealing Nut Hex (in) | 1.03 |
| B: Sealing Nut Hex (mm) | 26.2 |
| C: Body Nut OD (in) | 0.94 |
| C: Body Nut OD (mm) | 23.8 |
| D: Overall Length (in) | 1.31 |
| D: Overall Length (mm) | 33.3 |
| E: Exposed Length (in) | 0.81 |
| E: Exposed Length (mm) | 20.6 |
Documents
Suggested Related Products
- 2250
- LN 1/2 STEEL
$0.22233 / EA
×
